Debutante
1933 -
P-10
1934 -
P-12
1935 -
P-20
1935 -
P-30
1935 -
P-400
1935 -
312/316
1936 -
35
1936 -
400
1936 -
412/416
1936 -
50
1937 -
51 "Countertop"
1937 -
616
1937 -
616A
1937 -
716
1937 -
24
1938 -
500/500A
1938-1939 -
600/600A
1938-1939 -
600K
1938-1939 -
61 "Countertop"
1938-1939 -
700
1940 -
41
1940-1941 -
71
1940-1941 -
800
1941 -
780/780E "The Wagon Wheel"
1940-1941 -
750/750E
1941 -
850 "The Peacock"
1941 -
850A "The Tulip"
1941 -
81
1941-1942 -
950 "Gazelle"
1942 -
Victory Conversion
1942-1945 -
Victory Conversion with Rotary Wheel
1942-1945 -
Victory Conversion with Key Selection
1942-1945
The Debutante model design was purchased by the Wurlitzer Company to be utilized as a test model for the marketability of jukeboxes
| Model | Debutante |
|---|---|
| Year(s) | 1933 |
| Speed (rpm) | 78 |
| # Selections | 10 |
| # Records | 10 |
| Produced | ± 300 |
| Dimensions (HxWxD) | Unknown |
| Weight | Unknown |
| Model | P-10 |
|---|---|
| Year(s) | 1934 |
| Speed (rpm) | 78 |
| # Selections | 10 |
| # Records | 10 |
| Produced | ± 4.500 |
| Dimensions (HxWxD) | 123 x 76 x 53 cm (48.5 x 30 x 21") |
| Weight | Unknown |
| Model | P-12 |
|---|---|
| Year(s) | 1935 |
| Speed (rpm) | 78 |
| # Selections | 12 |
| # Records | 12 |
| Produced | ± 12.500 |
| Dimensions (HxWxD) | 124 x 84 x 58 cm (49 x 33 x 23") |
| Weight | Unknown |
| Model | P-20 |
|---|---|
| Year(s) | 1935 |
| Speed (rpm) | 78 |
| # Selections | 10 |
| # Records | 10 |
| Produced | ± 4.750 |
| Dimensions (HxWxD) | 119 x 84 x 56 cm (47 x 33 x 22") |
| Weight | Unknown |
| Model | P-30 |
|---|---|
| Year(s) | 1935 |
| Speed (rpm) | 78 |
| # Selections | 12 |
| # Records | 12 |
| Produced | ± 1.000 |
| Dimensions (HxWxD) | 126 x 76 x 55 cm (49.5 x 30 x 21.5") |
| Weight | Unknown |
| Model | P-400 |
|---|---|
| Year(s) | 1935 |
| Speed (rpm) | 78 |
| # Selections | 12 |
| # Records | 12 |
| Produced | ± 1.000 |
| Dimensions (HxWxD) | 131 x 91 x 61 cm (51.5 x 36 x 24") |
| Weight | Unknown |
| Model | 312/316 |
|---|---|
| Year(s) | 1936 |
| Speed (rpm) | 78 |
| # Selections | 312: 12, 316: 16 |
| # Records | 312: 12, 316: 16 |
| Produced | 312: ± 6.000, 316: ± 1.000 |
| Dimensions (HxWxD) | 130 x 79 x 56 cm (51 x 31 x 22") |
| Weight | Unknown |
| Model | 35 |
|---|---|
| Year(s) | 1936 |
| Speed (rpm) | 78 |
| # Selections | 12 |
| # Records | 12 |
| Produced | ± 250 |
| Dimensions (HxWxD) | 142 x 113 x 61 cm (56 x 44.5 x 24") |
| Weight | Unknown |
| Model | 400 |
|---|---|
| Year(s) | 1936 |
| Speed (rpm) | 78 |
| # Selections | 12 |
| # Records | 12 |
| Produced | ± 1.500 |
| Dimensions (HxWxD) | 131 x 91 x 61 cm (51.5 x 36 x 24") |
| Weight | Unknown |
| Model | 412/416 |
|---|---|
| Year(s) | 1936 |
| Speed (rpm) | 78 |
| # Selections | 412: 12, 416: 16 |
| # Records | 412: 12, 416: 16 |
| Produced | 412: ± 31.500, 416: ± 1.500 |
| Dimensions (HxWxD) | 124 x 86 x 58 cm (49 x 34 x 23") |
| Weight | Unknown |
| Model | 50 |
|---|---|
| Year(s) | 1937 |
| Speed (rpm) | 78 |
| # Selections | 12 |
| # Records | 12 |
| Produced | ± 1.250 |
| Dimensions (HxWxD) | 121 x 58 x 56 cm (47.5 x 23 x 18") |
| Weight | 75 kg (165 Lbs) |
| Model | 51 "Countertop" |
|---|---|
| Year(s) | 1937 |
| Speed (rpm) | 78 |
| # Selections | 12 |
| # Records | 12 |
| Produced | ± 1.250 |
| Dimensions (HxWxD) | 51 x 70 x 47 cm (20 x 27.5 x 18.5") |
| Weight | 54 kg (120 Lbs) |
| Model | 616 |
|---|---|
| Year(s) | 1937 |
| Speed (rpm) | 78 |
| # Selections | 16 |
| # Records | 16 |
| Produced | ± 23.500 |
| Dimensions (HxWxD) | 130 x 79 x 56 cm (51 x 31 x 22") |
| Weight | Unknown |
| Model | 616A |
|---|---|
| Year(s) | 1937 |
| Speed (rpm) | 78 |
| # Selections | 16 |
| # Records | 16 |
| Produced | ± 13.500 |
| Dimensions (HxWxD) | 130 x 79 x 56 cm (51 x 31 x 22") |
| Weight | 55 kg (121 Lbs) |
| USD107148 | Design for a phonograph cabinet |
| Model | 716 |
|---|---|
| Year(s) | 1937 |
| Speed (rpm) | 78 |
| # Selections | 16 |
| # Records | 16 |
| Produced | ± 2.750 |
| Dimensions (HxWxD) | 130 x 79 x 56 cm (51 x 31 x 22") |
| Weight | Unknown |
| USD103966 | Design for a phonograph cabinet |
First Model with 24 selections and illuminated plastics. Model 24A has new magnetic A.B.T coin selectors ("butterfly" switches)
| Model | 24/24A |
|---|---|
| Year(s) | 1938 |
| Speed (rpm) | 78 |
| # Selections | 24 |
| # Records | 24 |
| Produced | ± 16.750 |
| Dimensions (HxWxD) | 132 x 79 x 53 cm (52 x 31 x 21") |
| Weight | Unknown |
| Stepper | Wired: 304, Wireless: 305 |
| Wallbox | 310, 320, 330, 331, 332 |
| Cabinet Key | Front: F1133, Back: L1726 |
| USD111599 | Design for a phonograph cabinet |
Available in "G" or "P" version. G-500/G-500A has red outer pilasters, onyx grille plastics with moving grill colours. P-500/P-500A has onyx outer pilasters with colour cylinders, redgrille plastics.(shown) "A" versions have magnetic A.B.T coin selectors ("butterfly" switches)
| Model | 500/500A |
|---|---|
| Year(s) | 1938-1939 |
| Speed (rpm) | 78 |
| # Selections | 24 |
| # Records | 24 |
| Produced | ± 16.500 |
| Dimensions (HxWxD) | 150 x 89 x 71 cm (59 x 35 x 28") |
| Weight | 186 kg (410 Lbs) |
| USD112521 | Design for a phonograph cabinet |
Model 600A has magnetic A.B.T coin selectors ("butterfly" switches)
| Model | 600/600A |
|---|---|
| Year(s) | 1938-1939 |
| Speed (rpm) | 78 |
| # Selections | 24 |
| # Records | 24 |
| Produced | ± 12.750 |
| Dimensions (HxWxD) | 137 x 79 x 53 cm (54 x 31 x 21") |
| Weight | 152 kg (336 Lbs) |
| USD111702 | Design for a phonograph cabinet |
Similar to 600/600A with the addition of a Keyboard
| Model | 600K |
|---|---|
| Year(s) | 1938-1939 |
| Speed (rpm) | 78 |
| # Selections | 24 |
| # Records | 24 |
| Produced | ± 9.500 |
| Dimensions (HxWxD) | 137 x 79 x 53 cm (54 x 31 x 21") |
| Weight | 152 kg (336 Lbs) |
| USD111702 | Design for a phonograph cabinet |
Note: No stand available, although can be used on later produced stands for Wurlitzer 71 or 81
| Model | 61 "Countertop" |
|---|---|
| Year(s) | 1938-1939 |
| Speed (rpm) | 78 |
| # Selections | 12 |
| # Records | 12 |
| Produced | ± 8.250 |
| Dimensions (HxWxD) | 56 x 53 x 46 cm (22 x 21 x 18") |
| Weight | 52 kg (115 Lbs) |
| Cabinet Key | Front: J1287, Back: K1640 |
| USD112111 | Design for a phonograph cabinet |
Centre grille inspired on the "Trylon" and "Perisphere" landmark buildings shown, the year before, at the 1939 World Fair in New York
| Model | 700 |
|---|---|
| Year(s) | 1940 |
| Speed (rpm) | 78 |
| # Selections | 24 |
| # Records | 24 |
| Produced | ± 9.500 |
| Dimensions (HxWxD) | 144 x 81 x 65 cm (56.5 x 32 x 25.5") |
| Weight | 162 kg (357 Lbs) |
| Stepper | Wired: 304, Wireless: 305 |
| Wallbox | 310, 320, 330, 331, 332 |
| Cabinet Key | Front: LF50 , Back: TF25 |
Shown with optional stand 410
| Model | 41 "Countertop" |
|---|---|
| Year(s) | 1940-1941 |
| Speed (rpm) | 78 |
| # Selections | 12 |
| # Records | 12 |
| Produced | ± 2.000 |
| Dimensions (HxWxD) | 43 x 53 x 48 cm (17 x 21 x 19") |
| Weight | 48 kg (105 Lbs) |
Shown with optional stand 710
| Model | 71 "Countertop" |
|---|---|
| Year(s) | 1940-1941 |
| Speed (rpm) | 78 |
| # Selections | 12 |
| # Records | 12 |
| Produced | ± 4.500 |
| Dimensions (HxWxD) | 58 x 57 x 51 cm (23 x 22.5 x 20") |
| Weight | 66 kg (146 Lbs) |
| Wallbox | Non-selective wallbox |
| Cabinet Key | TF25 |
| Model | 800 |
|---|---|
| Year(s) | 1940 |
| Speed (rpm) | 78 |
| # Selections | 24 |
| # Records | 24 |
| Produced | ± 11.500 |
| Dimensions (HxWxD) | 155 x 94 x 71 cm (61 x 37 x 28") |
| Weight | 194 kg (428 Lbs) |
| Stepper | Wired: 304, Wireless: 305 |
| Wallbox | 310, 320, 330, 331, 332 |
| Cabinet Key | Front: LF50 , Back: TF25 |
780E has Electric selector kit
| Model | 780/780E "The Wagon Wheel" |
|---|---|
| Year(s) | 1940-1941 |
| Speed (rpm) | 78 |
| # Selections | 24 |
| # Records | 24 |
| Produced | 780: ± 2.900, 780E: ± 7.000 |
| Dimensions (HxWxD) | 155 x 97 x 64 cm (61 x 38 x 25") |
| Weight | 144 kg (317 Lbs) |
| Stepper | 145 |
| Remote speaker | 420, 421, 425, 430, 580 |
| Wallbox | 100, 115, 120, 123, 125, 430, 107, 111 |
| Cabinet Key | LF50 |
750E has Electric selector kit
| Model | 750/750E |
|---|---|
| Year(s) | 1941 |
| Speed (rpm) | 78 |
| # Selections | 24 |
| # Records | 24 |
| Produced | ± 13.000 |
| Dimensions (HxWxD) | 142 x 81 x 66 cm (56 x 32 x 26") |
| Weight | 140 kg (308 Lbs) |
| Stepper | 145 |
| Remote speaker | 420, 421, 425, 430, 580 |
| Wallbox | 100, 115, 120, 123, 125, 430, 107, 111 |
| Cabinet Key | LF50 |
| Model | 850 "The Peacock" |
|---|---|
| Year(s) | 1941 |
| Speed (rpm) | 78 |
| # Selections | 24 |
| # Records | 24 |
| Produced | ± 10.000 |
| Dimensions (HxWxD) | 166 x 99 x 67 cm (65.5 x 39 x 26.5") |
| Weight | 186 kg (410 Lbs) |
| Stepper | 145 |
| Remote speaker | 420, 421, 425, 430, 580 |
| Wallbox | 100, 115, 120, 123, 125, 430, 107, 111 |
| Cabinet Key | LF50 |
Only a very limited amount of the 850A were produced as the USA entered World War II and jukebox production at the Wurlitzer factory ceased
| Model | 850A "The Tulip" |
|---|---|
| Year(s) | 1941 |
| Speed (rpm) | 78 |
| # Selections | 24 |
| # Records | 24 |
| Produced | ± 450 |
| Dimensions (HxWxD) | 166 x 99 x 67 cm (65.5 x 39 x 26.5") |
| Weight | 186 kg (410 Lbs) |
| Stepper | 145 |
| Remote speaker | 420, 421, 425, 430, 580 |
| Wallbox | 100, 115, 120, 123, 125, 430, 107, 111 |
| Cabinet Key | LF50 |
Shown with optional stand 810 (a.k.a. "Mae West" stand)
| Model | 81 "Countertop" |
|---|---|
| Year(s) | 1941-1942 |
| Speed (rpm) | 78 |
| # Selections | 12 |
| # Records | 12 |
| Produced | ± 1.100 |
| Dimensions (HxWxD) | 60 x 57 x 51 cm (23.5 x 22.5 x 20") |
| Weight | 66 kg (146 Lbs) |
| Remote speaker | 420, 421, 425 |
| Cabinet Key | TF50 |
| Model | 950 "Gazelle" |
|---|---|
| Year(s) | 1942 |
| Speed (rpm) | 78 |
| # Selections | 24 |
| # Records | 24 |
| Produced | ± 3.500 |
| Dimensions (HxWxD) | 157 x 94 x 66 cm (62 x 37 x 26") |
| Weight | 167 kg (369 Lbs) |
During 1942, jukebox production at the Wurlitzer factory ceased and production was shifted to the manufacture of bomb proximity fuses until the end of World War II.
In order to keep existing customers, conversion of previous Wurlitzer models, to turn them into "Modernized Wurlitzers", was offered.
This Victory Conversion was a conversion of model 316, 416, 616 or 716
| Model | n.a. (Victory Conversion) |
|---|---|
| Year(s) | 1942-1945 |
| Speed (rpm) | 78 |
| # Selections | 16 |
| # Records | 16 |
| Produced | Unknown |
| Dimensions (HxWxD) | Unknown |
| Weight | Unknown |
During 1942, jukebox production at the Wurlitzer factory ceased and production was shifted to the manufacture of bomb proximity fuses until the end of World War II.
In order to keep existing customers, conversion of previous Wurlitzer models, to turn them into "Modernized Wurlitzers", was offered.
This Victory Conversion with Rotary Wheel was a conversion of model 24 or 600
| Model | n.a. (Victory Conversion with Rotary Wheel) |
|---|---|
| Year(s) | 1942-1945 |
| Speed (rpm) | 78 |
| # Selections | 24 |
| # Records | 24 |
| Produced | Unknown |
| Dimensions (HxWxD) | Unknown |
| Weight | Unknown |
During 1942, jukebox production at the Wurlitzer factory ceased and production was shifted to the manufacture of bomb proximity fuses until the end of World War II.
In order to keep existing customers, conversion of previous Wurlitzer models, to turn them into "Modernized Wurlitzers", was offered.
This Victory Conversion with Key Selection was a conversion of model 500, 600K, 700 or 800
| Model | n.a. (Victory Conversion with Key Selection) |
|---|---|
| Year(s) | 1942-1945 |
| Speed (rpm) | 78 |
| # Selections | 24 |
| # Records | 24 |
| Produced | Unknown |
| Dimensions (HxWxD) | Unknown |
| Weight | Unknown |
